Dune Freak 1.2m

Designed by Nick Chitty, reworked for laser cutting by Anglelwing Designs, the Dune Freak is a superb light wind slope soarer optimised for dunes and other tiny slope soaring sites. This beautiful balsa and carbon flying wing can also be flown from the flat using our Mini High Start.

• Flying Weight 175 – 200g
• Balsa and Carbon construction
• Carbon capped main spars
• Carbon Reinforced leading edge
• Carbon tube spar in Fin and Rudder
• Simple 2 channel Rudder Elevator controls
• Very tight turning Radius

Please see Nick Chittys Dune Freak Journey on Youtube.

Dune Freak 1.2m Specifications
Wing span	1.2 m	47 in
Wing area	19.7 dm2	305 sq in
Length	50 cm	19.8 in
Flying weight from	175 g	6.2 oz
Wing loading	8.9 g/dm	2.9 oz/sq ft
Aspect ratio	7.3
Wing airfoil	Proprietry
Dihedral angle (EDA)	11.0º (tip panels are 12.0º)
Centre of Gravity	30-32 mm from wing leading edge
Controls	Rudder, elevator
Battery space	20 x 20 x 80 mm
Nose weight + battery weight	approx 36 g

Like, Subscribe and comment on Nicks videos as it will help Nick to grow his channel.
